TYPE | DCL-1812 | S-DCL-1812 | |
---|---|---|---|
Laser Power | 1000W | 300W | |
Laser Type | The axis flow Co2 laser generator | (Co2 DC glass laser tube,water-cooled,10.6um) | |
Work Size | 1800X1250mm | ||
Cutting Speed | 25-10000mm/min | ||
Repeated positioning precision | ±0.015mm | ||
Minimal line-width | 0.45mm-0.71mm | ||
Supported File Format | DST、PLT、BMP、DXF、AI | ||
Compatible Software | CORELDRAW、PHOTOSHOP、ILLUSTRATOR、AUTOCAD | ||
Color Separation | reaches 256 colors to cut | ||
Power supply | 220V+5% 50HZ | ||
Power of total | 12KW | 4KW |
◆Use imported Servo Motor, good performance, fast response, maintenance-free.
◆Use ball screw transmission system, precision linear rolling guide, ensure running accuracy.
◆Use high-performance laser tube and laser power supply, laser power stability, durability, ensure work long time and without waste.
◆Use the laser industry's most advanced control system―― CA-control system
◆Unique intelligent predictive algorithm and improved control algorithm to ensure that processing speed, smooth and efficient
◆Operational speed, laser energy real-time tunable, and very easy for customers to operate
◆Cutting energy automatic compensation function, cutting greatly improved results
◆Using LAN interface, two-way communications, improved transmission speed and accuracy; One computer can controlled up to 254 laser equipment, greatly reduces customer investment and maintenance costs
