SERIES | CAP-BAB | CAP/2-BAB | ||
---|---|---|---|---|
TYPE |
CAP1610-BAB | CAP1810-BAB | CAP1610/2-BAB | CAP1810/2-BAB |
Laser Power |
50W/60W/90W/100W | |||
Laser Type |
CO2 sealed laser tube,water-cooled,10.6 um | |||
Work Size(mm) |
1600 × 1000 | 1800 × 1000 | 800 × 1000 × 2 | 900 × 1000 × 2 |
Cutting Speed |
25-40000mm/min | |||
Laser Energy Control |
real-timeadjustable | |||
Feeding way |
Automatic feed | |||
Feeding System |
Simple feeding device, Automatic correction feeding device (optional) | |||
Camera system |
18 million pixel HD SLR camera | |||
CCD field of view |
1600X1000 | 1800X1000 | 1600X1000 | 1800X1000 |
CCD detection accuracy |
0.5-2mm According to the shooting range adjustment | |||
Graphics Format Support |
DST,PLT,BMP,DXF,AI | |||
Software Support | TAJIMA,CORELDRAW,PHOTOSHOP,ILLUSTRATOR,AUTOCAD(all type of AUTOCAD software in cloth) | |||
Dichroic Cutting |
reaches 256 colors to cut | |||
Dimensions(mm) |
2400 × 1700 × 2600 | 2600 × 1700 × 2600 | 2400 × 1700 × 2600 | 2600 × 1700 × 2600 |
Total power |
1500-1700W | 2000-2200W |
◆Large format: maximum one-time processing 1800X1000mm graphics, to overturn the traditional camera cutting machine can process small graphical problems
◆High precision: can cope with complex graphics to achieve high-precision cutting, deformation matching algorithm, the deformation can be precisely cut format
◆Saving materials and environmental protection: multi-model cut and arranged parallel algorithms to improve efficiency, save material, automatic suction humidity and significantly improving the working environment
◆Suitable materials for a wide range: in addition to ordinary processed fabrics, but also joined the deformation matching algorithms to effectively solve the problem of high elastic cloth material cut after deformation
◆Configuration 1800W pixel digital camera, to achieve full-page second shot function,hundreds of samples, shoot second, one second match of advanced vision lighting system, effective guarantee uniformity of brightness of the visual field
Application Of Industry:
Trademarks, Mark weaving, embroidery, toys, gifts, clothing, luggage, leather goods, shoes, textiles, curtains etc.
Applicable Materials:
Cotton, hemp, chemical fiber and other textile and apparel fabrics and leather, wood, acrylic,cardboard and other non-metallic materials.
