TYPE | CC2513-ACE | CC1410-ACE |
---|---|---|
Laser Power | 150W,300W | |
Laser Types | Co2 sealed laser tube,water-cooled,10.6 um | |
Work Size | 2500mmX1300mm | 1300mmX1000mm |
Repeat positioning accuracy | ±0.05mm | |
Cutting Speed | 25-30000mm/min | |
> Laser Energy Control | Real-time adjustable | |
Auxiliary gas | Metal:o2 Nonmetal:Air | |
Software Support | TAJIMA、CORELDRAW、PHOTOSHOP、ILLUSTRATOR、AUTOCAD | |
Dichroic Cutting | reaches 256 colors to cut | |
Dimensions Cooling mode(mm) | 4020mm×2200mm×1195mm | 2060mm×1780mm×1160mm |
Total power | 4000-6000W | 3000-5000W |
◆Adopts panasonic servo drive system, imported bearing,greatly improve the equipment running speed and stability
◆Openness of the platform to facilitate the processing of materials available, and work with Pipeline
◆Large-scale processing and meet the large number of processing
◆Use high quality laser tube,cuting faster and more stable
◆Use the laser industry's most advanced control system,ensure fast processing, stable and efficient
◆Unique intelligent predictive algorithm and improved control algorithm to ensure that processing speed, smooth and efficient
◆Operational speed, laser energy real-time tunable, and very easy for customers to operate
◆Cutting energy automatic compensation function, cutting greatly improved results
◆High precision laser cutting servo system,the laser head and the material always maintain the best cutting distance
Application Of Industry:
Decorative industry, the furniture industry, advertising,packaging and printing industry, model industry, process gifts and so on.
Applicable Materials:
Stainless steel、carbon steel、acrylic、density board、etc.
