Imported servo motor and screw guide rail Dual-drive,Imported servo motor and screw guide rail.
| TYPE | LCF2513 | LCF3015 | LCF0605 |
|---|---|---|---|
| Laser Power | 500-1000W | ||
| Laser wavelength | 1064nm | ||
| Work Size | 2500mmX1300mm | 3000mmX1500mm | 600mmX500mm |
| Min-laser beam | 0.05mm | ||
| Driving mode | |||
| Maximum movement velocity | 20000mm/min | 60000mm/min | |
| dimension accuracy | ±0.06mm/m | ||
| Position accuracy | ±0.02mm/m | ||
| Repeated positioning precision | ±0.015mm/m | ||
| Cooling mode | Water cooled | ||
| Supported File Format | G code 、PLT、DXF | ||
| Electric power requirement | 380V/50Hz | ||
| Average power | 3.5-12KW | ||
◆Imported fiber laser tube, stable performance, its life can reach more than 100000 hours.
◆Laser tube is free maintenance, greatly reduce the cost for customer.
◆Fiber laser has 30% of the electro-optical conversion,with energy conservation and environmental protection.
◆Excellent beam quality and focal sp smaller, cutting edge are of good quality, small deformation, smooth and beautiful appearance
◆Using imported servo motor and screw guide rail, high cutting precision.
Application Of Industry：It is applicable to different of metalwork processing industries like sheet-metal processing,advertising,laser processing service etc.
Applicable Materials：It is mainly used in quick cutting of various metal materials like carbon steel,silicon steel,stainless steel,titaniumalloy,galvanized sheet,pickling boards etc.
